更新记录

1.1.3（2024-04-08）

安卓增加气泡展示功能

1.1.2（2024-04-07）

安卓增加地图手动释放，避免多次进入后出现黑屏

1.1.1（2024-04-07）

增加显示自身位置时，控制地图是否自动归位

平台兼容性

pow-amapall

开发文档

UTS 语法 UTS API插件 UTS 组件插件 Hello UTS

高德定位、地图、导航全功能插件，功能持续增加中

使用步骤

1. 申请高德key
2. 导入本插件
3. 打自定义基座
4. 高德key通过setAmapKey方法传入插件，并且调用隐私协议方法amapPrivacyDidShow和amapUserDidAgreePrivacy
5. 调用定位、导航、地图、TTS相关方法

定位、导航、TTS功能

<template>
    <view class="container">
        <view class="title">定位权限</view>
        <button @click="jianchadingweiquanxian">申请定位权限</button>
        <view class="title">定位功能</view>
        <button @click="getOnceLocation">高德单次定位</button>
        <button @click="startLocation">开始持续后台定位</button>
        <button @click="stopLocation">结束持续后台定位</button>
        <view class="title">地图功能</view>
        <button @click="gotoMapView">进入地图页面</button>
        <button @click="gotoOffline">管理离线地图</button>
        <view class="title">导航功能</view>
        <button @click="daohang">开始高德导航</button>
        <view class="title">TTS功能</view>
        <input class="voice-input" placeholder="播放文字" :value="ttsText" @input="inputTTSText" />
        <button @click="readTTS">播放上面的文字</button>

    </view>
</template>

<script>
    import {
        amapPrivacyDidShow,
        amapUserDidAgreePrivacy,
        setAmapKey,
        getAmapLocation,
        startAmapLocation,
        stopAmapLocation,
        startAmapNavi,
        amapTTS,
        manageOfflineMap,
        checkAndRequestLocationPermission
    } from '@/uni_modules/pow-amapall'

    export default {
        data() {
            return {
                ttsText: '我是文字转语音,支持英语,hello'
            }
        },
        onReady() {
            uni.setNavigationBarTitle({
                title: '高德demo'
            })

            amapPrivacyDidShow()
            amapUserDidAgreePrivacy()
            setAmapKey('2d3da96f1736d9403288c6ed95a5e85f', '72566fdc715020e355f355e4d9b7ceb1') // 参数依次是ioskey、安卓key

        },
        methods: {
            jianchadingweiquanxian() {
                checkAndRequestLocationPermission((res) => {
                    console.log(`请求权限结果:${JSON.stringify(res)}`)
                    uni.showToast({
                        title: `请求权限结果:${res.msg}`,
                        icon: 'none'
                    })
                })
            },
            gotoOffline(){
                manageOfflineMap()
            },
            gotoMapView() {
                uni.navigateTo({
                    url: './mapview'
                })
            },
            inputTTSText(e) {
                console.log('输入了文字：', e.detail.value)
                this.ttsText = e.detail.value
            },
            readTTS() {
                if (this.ttsText == '') {
                    uni.showToast({
                        title: '输入播放文字',
                        icon: 'error'
                    })
                    return
                }
                amapTTS(this.ttsText)
            },
            getOnceLocation() {
                uni.showLoading({
                    title: '获取定位',
                    mask: true
                })
                getAmapLocation({
                    needAddress: true, //是否需要返回位置描述文字信息，此功能需要iOS和安卓的key在高德后台正确配置
                    accuracy: 100 //期望的定位精度，单位：米，一般填 5 、100、200 ，精度越低速度越快
                }, res => {
                    let log = `单次定位回调 ${JSON.stringify(res)}`
                    console.log(log)
                    uni.hideLoading()
                    uni.showToast({
                        title: log,
                        icon: 'none'
                    })
                })
            },
            startLocation() {
                startAmapLocation({
                    need_bg: true, //默认需要后台定位，插件内会实现高德的推荐方案，出现通知栏展示持续定位中。参考： https://lbs.Amap.com/faq/api?title=android-locsdk/guide/addition-func/android8-notice。如果不需要，传入false即可
                    needAddress: true, //是否需要返回位置描述文字信息，此功能需要iOS和安卓的key在高德后台正确配置
                    bg_title: '正在后台定位', //安卓机器后台定位时通知栏展示的文字,
                    interval: 2000 //定位周期，单位毫秒，不传的话默认2000ms
                }, (res) => {
                    // res是回调结果，拿到之后可以自己处理
                    let log = `定位回调 ${JSON.stringify(res)}`
                    console.log(log)
                    uni.showToast({
                        title: log,
                        icon: 'none'
                    })
                })
            },
            stopLocation() {
                stopAmapLocation()
            },
            daohang() {
                let naviTypeOptions = [{
                    title:'驾车',
                    type:'drive'
                },{
                    title:'骑行',
                    type:'ride'
                },{
                    title:'步行',
                    type:'walk'
                }]
                uni.showActionSheet({
                    title: '骑行方式',
                    itemList: naviTypeOptions.map(item => `${item.title}`),
                    success: (res) => {
                        let naviType = naviTypeOptions[res.tapIndex].type
                        startAmapNavi({
                            // --------------------必传参数----------------------
                            end: {
                                lon: 118.798039,
                                lat: 31.96875,
                                name: '南京南站',
                                poiId: 'B00190YPLY' //name和poiId可以不设置
                            },

                            // --------------------可选参数----------------------
                            startNaviDirectly: true, //是否跳过路径规划页面，默认为false
                            naviType: naviType, //默认为'drive'
                            start: {
                                lon: 118.779613,
                                lat: 32.055085,
                                name: '南京大学鼓楼校区',
                                poiId: 'B00190B4AC'
                            },
                            via: [{
                                poiId: "B001905HYA",
                                name: "南京站",
                                lon: 118.797499,
                                lat: 32.087104
                            }], //只有驾车导航支持途径点，骑行和步行不支持途径点

                        }, (res) => {
                            // res是回调结果，拿到之后可以自己处理
                            let log = `导航回调 ${JSON.stringify(res)}`
                            console.log(log)
                            uni.showToast({
                                title: log,
                                icon: 'none'
                            })
                        })
                    }
                })

            }

        }
    }
</script>

<style>
    page {
        width: 100%;
        height: 100%;
        background-color: white;
    }
    .container{
        width: 100%;
        background-color: white;
        padding-bottom: 20rpx;
    }
    button {
        margin: 10px 10px 0 10px;
    }

    .voice-input {
        border-radius: 4px;
        border: 1px solid #ccc;
        margin-top: 10px;
        margin-left: 10px;
        margin-right: 10px;
        padding: 5px;
    }

    .title {
        margin-top: 20px;
        margin-left: 10px;
        font-size: 20px;
        font-weight: bold;
    }
</style>

地图功能

<template>
    <view class="container">
        <view class="map-container">
            <pow-amapall class="map" ref='amap' @markerClick='markerBeiDianJiLe'></pow-amapall>
        </view>
        <view class="options">
            <button type="primary" class="controlbtn" size="mini" @click="jianchadingweiquanxian">检查定位权限</button>
            <button type="primary" class="controlbtn" size="mini"
                @click="showzijiweizhi">{{didShowMyLocation?'隐藏':'展示'}}自己位置</button>
            <button type="primary" class="controlbtn" size="mini" @click="qiehuantuceng">切换图层</button>
            <button type="primary" class="controlbtn" size="mini"
                @click="showlukuangxinxi">{{didShowTraffic?'隐藏':'展示'}}路况信息</button>
            <button type="primary" class="controlbtn" size="mini"
                @click="showguiweianniu">{{didShowMyLocationBtn?'隐藏':'展示'}}归位按钮</button>
            <button type="primary" class="controlbtn" size="mini"
                @click="showbilichi">{{didShowScaleSize?'隐藏':'展示'}}比例尺可见</button>
            <button type="primary" class="controlbtn" size="mini"
                @click="showsuofanganniu">{{didShowZoomBtn?'隐藏':'展示'}}缩放按钮</button>
            <button type="primary" class="controlbtn" size="mini"
                @click="showzhinanzhenanniu">{{didShowCompassBtn?'隐藏':'展示'}}指南针按钮</button>
            <button type="primary" class="controlbtn" size="mini"
                @click="enablesuofangshoushi">{{enableZoomGesture?'禁止':'允许'}}缩放手势</button>
            <!-- 拖拽，倾斜，旋转手势控制 -->
            <button type="primary" class="controlbtn" size="mini"
                @click="enabletuozhuaishoushi">{{enableScrollGesture?'禁止':'允许'}}拖拽手势</button>
            <button type="primary" class="controlbtn" size="mini"
                @click="enableqingxieshoushi">{{enableTiltGesture?'禁止':'允许'}}倾斜手势</button>
            <button type="primary" class="controlbtn" size="mini"
                @click="enablexuanzhuanshoushi">{{enableRotateGesture?'禁止':'允许'}}旋转手势</button>
            <button type="primary" class="controlbtn" size="mini"
                @click="zhongyingwen">切换到{{switchToLanguage}}文地图</button>
            <button type="primary" class="controlbtn" size="mini" @click="getdituzhongxindian">获取地图中心点</button>
            <button type="primary" class="controlbtn" size="mini" @click="movedituzhongxindian">移动地图中心点</button>
            <button type="primary" class="controlbtn" size="mini" @click="suofangditu">缩放地图</button>
            <button type="primary" class="controlbtn" size="mini" @click="shezhisuofangfanwei">设置缩放范围</button>
            <button type="primary" class="controlbtn" size="mini" @click="tianjiamarker">添加marker</button>
            <button type="primary" class="controlbtn" size="mini" @click="shanchumarker">删除指定marker</button>
            <button type="primary" class="controlbtn" size="mini" @click="shanchusuoyoumarker">删除所有marker</button>
            <button type="primary" class="controlbtn" size="mini" @click="huazhexian">画折线</button>
            <button type="primary" class="controlbtn" size="mini" @click="shanchuzhexian">删除某条折线</button>
            <button type="primary" class="controlbtn" size="mini" @click="shanchusuoyouzhexian">删除所有折线</button>
            <button type="primary" class="controlbtn" size="mini" @click="huayuanxing">画圆形</button>
            <button type="primary" class="controlbtn" size="mini" @click="shanchuyuanxing">删除某个圆形</button>
            <button type="primary" class="controlbtn" size="mini" @click="shanchusuoyouyuanxing">删除所有圆形</button>
            <button type="primary" class="controlbtn" size="mini" @click="huaduobianxing">画多边形</button>
            <button type="primary" class="controlbtn" size="mini" @click="shanchuduobianxing">删除某个多边形</button>
            <button type="primary" class="controlbtn" size="mini" @click="shanchusuoyouduobianxing">删除所有多边形</button>
            <button type="primary" class="controlbtn" size="mini" @click="suofangbaohanmarkers">缩放以包含marker</button>
            <button type="primary" class="controlbtn" size="mini" @click="pinghuayidong">点平滑移动</button>

        </view>

    </view>
</template>

<script>
    import {
        checkAndRequestLocationPermission
    } from '@/uni_modules/pow-amapall'
    let _markers = [{
        id: 'uuid111', //marker的唯一id，不能重复
        lat: 39.909187,
        lng: 116.397455,
        title: '天安门',
        subtitle: '天安门城楼',
        icon: 'https://s11.ax1x.com/2023/03/17/ppGtKhD.png', //目前只支持网络图片，免费生成网络图片的地址 imgse.com
        iconWidth: 75,
        iconHeight: 75, //单位 px , iconWidth和iconHeight成对传，否则不生效
        anchor: 'center' // center 图片中间对准经纬度(常用于表示车辆行驶在路上)，bottomCenter 图片底部中间对准经纬度(常用于扎针标记位置)，默认值center
    }, {
        id: 'uuid222', //marker的唯一id，不能重复
        title: '王府井',
        lat: 39.909187,
        lng: 116.412555,
        subtitle: '王府井大街',
        anchor: 'bottomCenter' ,// center 图片中间对准经纬度(常用于表示车辆行驶在路上)，bottomCenter 图片底部中间对准经纬度(常用于扎针标记位置)，默认值center
        callout:{
            content:'这是一个自定义的气泡',
            textColor:'#ff8800',
            fontSize:20,
            textAlign:'center',
            borderRadius:10,
            borderColor:'#ff0000',
            borderWidth:3,
            bgColor:'#ffffff',
            padding:20
        }
    }]
    let polyline = {
        id: 'polyline111', //折线的唯一id，不能重复
        points: [
            '116.362209,39.887487',
            '116.422897,39.878002',
            '116.372105,39.90651',
            '116.428945,39.89663'
        ],
        width: 20,
        isDottedLine: true,
        color: '#ff0000',
    }
    let circle = {
        id: 'circle111', //圆形的id，不能重复
        lat: 39.909187,
        lng: 116.397455, //圆心经纬度
        radius: 1000, //单位 m
        lineWidth: 5,
        strokeColor: '#FF0000',
        fillColor: '#00ffff',
    }
    let polygon = {
        id: 'polygon111', //多边形的id，不能重复
        points: [
            '116.404,39.915',
            '116.408,39.917',
            '116.412,39.919',
            '116.412,39.921',
            '116.410,39.923',
            '116.406,39.923',
            '116.404,39.921'
        ],
        lineWidth: 5,
        strokeColor: '#FF0000',
        fillColor: '#00ffff',
    }

    export default {
        data() {
            return {
                didShowMyLocation: false,
                didShowTraffic: false,
                didShowMyLocationBtn: false,
                didShowZoomBtn: true,
                didShowCompassBtn: false,
                enableZoomGesture: true,
                enableScrollGesture: true,
                enableTiltGesture: true,
                enableRotateGesture: true,
                didShowScaleSize: true,
                switchToLanguage:'英'
            }
        },
        methods: {
            zhongyingwen(){
                let params = {
                    switchToLanguage:this.switchToLanguage //入参可选：中/英
                }
                this.$refs.amap.changeLanguage(JSON.stringify(params))

                if(this.switchToLanguage=='英'){
                    this.switchToLanguage='中'
                }else{
                    this.switchToLanguage='英'
                }
            },
            pinghuayidong() {
                this.$refs.amap.zoomTo(JSON.stringify({
                    zoomLevel: 13
                }))
                let testPoints = [
                    '116.37,39.91',
                    '116.380298, 39.907771',
                    '116.38, 39.90',
                    '116.385298, 39.907771',
                    '116.40, 39.90',
                    '116.40772, 39.909252',
                    '116.41, 39.89',
                    '116.423857, 39.889498',
                    '116.422312, 39.899639',
                    '116.425273, 39.902273'
                ]
                //画一条线，方便观察移动轨迹
                let polylinexxx = {
                    id: 'polylinexxx', //折线的唯一id，不能重复
                    points: testPoints,
                    width: 10,
                    isDottedLine: false,
                    color: '#ff0000',
                }
                this.$refs.amap.drawPolyline(JSON.stringify(polylinexxx))

                // 开始添加一个平滑移动的marker
                let options = {
                    points: testPoints,
                    icon: 'https://s21.ax1x.com/2024/03/13/pFcsHVP.png', //目前只支持网络图片，免费生成网络图片的地址 imgse.com
                    duration: 10, //单位 秒
                    id: 'animate111', // 用来做删除和多次平滑移动，如果要实现多次移动同一个marker，多次调用addMoveAnimation时传相同id即可
                    removeMarkerWhenFinish: true, //动画结束后是否需要移除
                    iconWidth: 75,
                    iconHeight: 75,
                    anchor: 'center' //可选项： center 图片中间对准经纬度(常用于表示车辆行驶在路上)，bottomCenter 图片底部中间对准经纬度(常用于扎针标记位置)，默认值center
                }

                this.$refs.amap.addMoveAnimation(JSON.stringify(options))
            },
            qiehuantuceng() {
                const options = [{
                        title: '导航',
                        type: 'navi'
                    },
                    {
                        title: '卫星',
                        type: 'satellite'
                    },
                    {
                        title: '普通(默认)',
                        type: 'normal'
                    },
                    {
                        title: '夜景',
                        type: 'night'
                    },
                    {
                        title: '导航夜景',
                        type: 'navinight'
                    },
                    {
                        title: '公交',
                        type: 'bus'
                    }
                ]
                uni.showActionSheet({
                    title: '切换图层',
                    itemList: options.map(item => `${item.type}`),
                    success: (res) => {
                        let params = {
                            mapType: options[res.tapIndex].type
                        }
                        this.$refs.amap.setMapType(JSON.stringify(params))
                    }
                })
            },
            suofangbaohanmarkers() {
                console.log('缩放地图以包含给定的多个marker，并且设置边界空白')
                let params = {
                    markers: _markers,
                    paddingTop: 50, // 单位，像素
                    paddingBottom: 50,
                    paddingLeft: 50,
                    paddingRight: 50,
                    animated: true
                }

                this.$refs.amap.setVisibleIncludeMarkers(JSON.stringify(params))
            },
            markerBeiDianJiLe(markInfo) {
                console.log(`demo收到添加的marker被点击了:${markInfo.detail}`)
            },
            huayuanxing() {
                this.$refs.amap.drawCircle(JSON.stringify(circle))
            },
            shanchuyuanxing() {
                this.$refs.amap.removeCircle(JSON.stringify(circle))
            },
            shanchusuoyouyuanxing() {
                this.$refs.amap.removeAllCircles()
            },
            huaduobianxing() {
                this.$refs.amap.drawPolygon(JSON.stringify(polygon))
            },
            shanchuduobianxing() {
                this.$refs.amap.removePolygon(JSON.stringify(polygon))
            },
            shanchusuoyouduobianxing() {
                this.$refs.amap.removeAllPolygons()
            },
            shanchusuoyouzhexian() {
                this.$refs.amap.removeAllPolylines()
            },
            shanchuzhexian() {
                this.$refs.amap.removePolyline(JSON.stringify(polyline))
            },
            huazhexian() {
                this.$refs.amap.drawPolyline(JSON.stringify(polyline))
            },
            shezhisuofangfanwei() {
                let zoomLevel = {
                    min: 10,
                    max: 15
                }
                this.$refs.amap.setMinAndZoomLevel(JSON.stringify(zoomLevel))
                uni.showToast({
                    title: '设置了缩放范围是10-15',
                    icon: 'none'
                })
            },
            shanchusuoyoumarker() {
                this.$refs.amap.removeAllMarkers()
            },
            shanchumarker() {
                this.$refs.amap.removeSomeMarkers(JSON.stringify(_markers))
            },
            tianjiamarker() {
                this.$refs.amap.addMarkers(JSON.stringify(_markers))
            },
            suofangditu() {
                let zoomOptions = [0, 5, 10, 14, 17, 21]
                uni.showActionSheet({
                    title: '设置缩放级别(0到21都行)',
                    itemList: zoomOptions.map(item => item + '级'),
                    success: (res) => {
                        let param = {
                            zoomLevel: zoomOptions[res.tapIndex]
                        }
                        let paramString = JSON.stringify(param)
                        this.$refs.amap.zoomTo(paramString)
                    }
                })
            },
            movedituzhongxindian() {
                const options = [{
                        title: '北京天安门',
                        lat: 39.909187,
                        lng: 116.397455,
                    },
                    {
                        title: '上海迪士尼',
                        lat: 31.231706,
                        lng: 121.67269,
                    },
                    {
                        title: '敦煌莫高窟',
                        lat: 40.037403,
                        lng: 94.805872,
                    },
                    {
                        title: '广州塔',
                        lat: 23.129163,
                        lng: 113.26444,
                    },
                    {
                        title: '布达拉宫',
                        lat: 29.654471,
                        lng: 91.118463,
                    }

                ]
                uni.showActionSheet({
                    title: '选择一个中心点',
                    itemList: options.map(item => `${item.title}:${item.lat},${item.lng}`),
                    success: (res) => {
                        let param = {
                            lng: options[res.tapIndex].lng,
                            lat: options[res.tapIndex].lat
                        }
                        let paramString = JSON.stringify(param)
                        this.$refs.amap.moveTo(paramString)
                    }
                })
            },
            // 未完成，uts有bug，无法获取返回值,也无法传入一个方法
            getdituzhongxindian() {
                let cameraInfoObj = this.$refs.amap.getCameraInfo()
                console.log(`调用方获取到的中心点:${JSON.stringify(cameraInfoObj)}`);
                uni.showToast({
                    title: `(uts暂不支持)中心点：${JSON.stringify(cameraInfoObj)}`,
                    icon: 'none'
                })

            },
            showbilichi() {
                this.$refs.amap.showScaleSize(!this.didShowScaleSize)
                this.didShowScaleSize = !this.didShowScaleSize
            },
            enabletuozhuaishoushi() {
                this.$refs.amap.enableScrollGesture(!this.enableScrollGesture)
                this.enableScrollGesture = !this.enableScrollGesture
            },
            enableqingxieshoushi() {
                this.$refs.amap.enableTiltGesture(!this.enableTiltGesture)
                this.enableTiltGesture = !this.enableTiltGesture
            },
            enablexuanzhuanshoushi() {
                this.$refs.amap.enableRotateGesture(!this.enableRotateGesture)
                this.enableRotateGesture = !this.enableRotateGesture
            },
            enablesuofangshoushi() {
                this.$refs.amap.enableZoomGesture(!this.enableZoomGesture)
                this.enableZoomGesture = !this.enableZoomGesture
            },
            showzhinanzhenanniu() {
                this.$refs.amap.showCompassBtn(!this.didShowCompassBtn)
                this.didShowCompassBtn = !this.didShowCompassBtn
            },
            showsuofanganniu() {
                this.$refs.amap.showZoomBtn(!this.didShowZoomBtn)
                this.didShowZoomBtn = !this.didShowZoomBtn
            },
            jianchadingweiquanxian() {
                checkAndRequestLocationPermission((res) => {
                    console.log(`请求权限结果:${JSON.stringify(res)}`)
                    uni.showToast({
                        title: `请求权限结果:${res.msg}`,
                        icon: 'none'
                    })
                })
            },
            showzijiweizhi() {
                let params = {
                    show:!this.didShowMyLocation, //是否展示自身位置
                    updatingMapCenter:false //是否根据自身位置移动地图
                }
                this.$refs.amap.showMyLocation(JSON.stringify(params))
                this.didShowMyLocation = !this.didShowMyLocation
            },
            showlukuangxinxi() {
                this.$refs.amap.showTraffic(!this.didShowTraffic)
                this.didShowTraffic = !this.didShowTraffic
            },
            showguiweianniu() {
                this.$refs.amap.showMyLocationBtn(!this.didShowMyLocationBtn)
                this.didShowMyLocationBtn = !this.didShowMyLocationBtn
            }

        }
    }
</script>

<style>
    .map-container {
        width: 750rpx;
        height: 550rpx;
    }

    .container {
        display: flex;
        flex-direction: column;
        width: 750rpx;
    }

    .map {
        width: 750rpx;
        height: 550rpx;
    }

    .controlbtn {
        width: 120px;
        margin-left: 5px;
        margin-top: 3px;
    }

    .options {
        display: flex;
        flex-direction: row;
        flex-wrap: wrap;
        width: 750rpx;
        padding-top: 10rpx;
        padding-bottom: 20rpx;

    }
</style>
