更新记录

1.0.7(2021-08-18)

修复 Android 原生编码 bug

1.0.6(2021-08-09)

  1. 升级 SDK 插件示例工程,添加js配置文件;
  2. 添加服务端旁路推流接口:
    • addPublishStreamUrl 增加旁路推流地址.
    • removePublishStreamUrl 删除旁路推流地址.
    • setLiveTranscoding 设置直播转码参数.
查看更多

平台兼容性

Android iOS
适用版本区间:4.4 - 11.0 适用版本区间:9 - 14

原生插件通用使用流程:

  1. 购买插件,选择该插件绑定的项目。
  2. 在HBuilderX里找到项目,在manifest的app原生插件配置中勾选模块,如需要填写参数则参考插件作者的文档添加。
  3. 根据插件作者的提供的文档开发代码,在代码中引用插件,调用插件功能。
  4. 打包自定义基座,选择插件,得到自定义基座,然后运行时选择自定义基座,进行log输出测试。
  5. 开发完毕后正式云打包

付费原生插件目前不支持离线打包。
Android 离线打包原生插件另见文档 https://nativesupport.dcloud.net.cn/NativePlugin/offline_package/android
iOS 离线打包原生插件另见文档 https://nativesupport.dcloud.net.cn/NativePlugin/offline_package/ios

注意事项:使用HBuilderX2.7.14以下版本,如果同一插件且同一appid下购买并绑定了多个包名,提交云打包界面提示包名绑定不一致时,需要在HBuilderX项目中manifest.json->“App原生插件配置”->”云端插件“列表中删除该插件重新选择


anyRTC 音视频SDK

anyRTC移动视频直播、实时互动连麦视频(音频)直播、小程序互动直播、视频会议等解决方案提供商。本插件提供实时音视频能力,支持Android、iOS。

集成中如需帮助,可以通过以下方式联系我们:

  • anyRTC官网,右下方在线客服
  • QQ技术交流群:580477436
  • 联系电话:021-65650071
  • Email:hi@dync.cc

跑通代码需要自定义基座,并且使用iOS和安卓真机运行

概要

  • anyRTC音视频品质首选,每月免费赠送1万分钟实时音频;
  • anyRTC提供rtm服务,轻松实现交互逻辑;
  • 为了帮助中小企业在音视频领域轻松打造爆款应用,详情anyRTC创业扶持计划。

快速集成

  • 下载示例工程,前往anyRTC官网注册账号

  • 创建应用,获取应用的App ID。

appid

  • 下载插件示例工程,制作自定义基座,主要步骤如图,证书问题,请参照申请证书说明。

自定义基座

  • 运行自定义基座 运行自定义基座

  • 运行示例工程开始体验

一、AR-RtcModule

函数名 参数 说明
create appId(String) 创建rtc对象
setCallBack 注册sdk事件回调
setParameters 咨询客服 通过 JSON 配置 SDK 提供技术预览或特别定制功能
joinChannel channelId(String)、uid(String)、token(String) 加入房间
enableAudio 开启音频
enableVideo 开启视频
disableAudio 禁用音频
disableVideo 禁用视频
setAudioProfile profile(int)、scenario(int) 设置声音的profile
enableInEarMonitoring enabled(bool) 开启耳返
setInEarMonitoringVolume volume(int) 设置耳返音量
setChannelProfile profile(int) 设置模式
setClientRole role(int) 设置用户角色
playEffect soundId(int)、filePath(string)、loopCount(int)、pitch(double)、pan(double)、gain(double)、publish(bool) 播放音效
stopAllEffects 停止播放所有音频效果
stopEffect soundId(int) 停止播放音频效果
adjustAudioMixingVolume volume(int) 音频混合音量
startAudioMixing filePath(string)、loopback(bool)、replace(bool)、cycle(int) 开始播放混音
stopAudioMixing 停止播放混音
leaveChannel 离开频道
destroyRtc 释放ARtcEngineKit对象资源
switchCamera 切换摄像头
setDefaultAudioRouteToSpeakerphone defaultToSpeaker(bool) 设置默认音频路由
setEnableSpeakerphone enabled(bool) 设置是否将音频路由到扬声器或听筒
isSpeakerphoneEnabled 检查扬声器是否已启用
enableAudioVolumeIndication interval(int)、smooth(int)、report_vad(bool) 是否开启音频检测
adjustRecordingSignalVolume volume(int) 录音音量。值的范围在0到400之间
adjustUserPlaybackSignalVolume uid(string)、volume(int) 指定的远程用户的播放音量。值的范围为0到100
adjustPlaybackSignalVolume volume(int) 所有远程用户的播放音量。值的范围为0到400
enableLocalAudio enabled(bool) 启用本地音频模块,即启动本地音频捕获和处理
enableLocalVideo enabled(bool) 启用设置是否启用/禁用本地视频,包括捕获器、渲染器和发送器
muteLocalAudioStream muted(bool) 发送或停止本地音频流
muteLocalVideoStream muted(bool) 发送或停止本地视频流
muteRemoteAudioStream uid(string)、muted(bool) 接收或停止接收指定的远程用户的音频流
muteRemoteVideoStream uid(string)、muted(bool) 设置是否接收/停止接收指定远程用户的视频流
muteAllRemoteAudioStreams muted(bool) 是否接收/停止接收所有远程音频流
muteAllRemoteVideoStreams muted(bool) 是否接收/停止接收所有远程视频流
setDefaultMuteAllRemoteAudioStreams muted(bool) 设置默认情况下是否接收/停止接收所有远程音频流
setDefaultMuteAllRemoteVideoStreams muted(bool) 设置默认情况下是否接收/停止接收所有远程视频流
setCameraTorchOn isOn(bool) 是否开启闪光灯
isCameraTorchSupported 是否支持闪光灯
setVideoEncoderConfiguration width(int)、height(int)、frameRate(int)、bitrate(int)、orientationMode(int) 设置视频编码配置
addPublishStreamUrl url(string)、transcodingEnabled(bool) 增加旁路推流地址
removePublishStreamUrl url(string) 删除旁路推流地址
setLiveTranscoding transcoding(LiveTranscoding) 设置直播转码参数

更多 API 调用详见anyRTC文档

callBack

{"code": 0}

code值详见anyRTC文档

二、AR-CanvasView

函数名 参数 说明
startPreview 开启视频预览
stopPreview 停止视频预览
setupLocalVideo uid(string)、channelId(string)、renderMode(int)、mirrorMode(int) 初始化本地视图
setupRemoteVideo uid(string)、channelId(string)、renderMode(int)、mirrorMode(int) 初始化远端用户视图

三、事件回调

  1. 发生警告回调(onWarning)
    {"engineEvent": "onWarning", "warningCode": 0}

2.发生错误回调()

{"engineEvent": "", "errorCode": 0}

3.加入频道回调(onJoinChannelSuccess)

{"engineEvent": "onJoinChannelSuccess", "channel": "909090", "uid": "123", "elapsed": 0}

4.重新加入频道回调(onRejoinChannelSuccess)

{"engineEvent": "onRejoinChannelSuccess", "channel": "909090", "uid": "123", "elapsed": 0]

5.已离开频道回调(onLeaveChannel)

{"engineEvent": "onLeaveChannel", "duration": 0, "txBytes": 0, "rxBytes": 0, "txAudioBytes": 0, "txVideoBytes": 0, "rxAudioBytes": 0, "rxVideoBytes": 0, "txKBitrate": 0, "rxKBitrate": 0, "txAudioKBitrate": 0, "rxAudioKBitrate": 0, "txVideoKBitrate": 0, "rxVideoKBitrate": 0, "lastmileDelay": 0, "txPacketLossRate": 0, "rxPacketLossRate": 0, "userCount": 0, "cpuAppUsage": 0.0, "cpuTotalUsage": 0.0, "gatewayRtt": 0, "memoryAppUsageRatio": 0.0, "memoryTotalUsageRatio": 0.0, "memoryAppUsageInKbytes": 0}

6.用户角色已切换回调(onClientRoleChanged)

{"engineEvent": "onClientRoleChanged", "oldRole": 0, "newRole": 1}

7.远端用户/主播加入回调(onUserJoined)

{"engineEvent": "onUserJoined", "uid": "123", "elapsed": 0}

8.远端用户(通信场景)/主播(直播场景)离开当前频道回调(onUserOffline)

{"engineEvent": "onUserOffline", "uid": "123", "reason": 0}

9.网络连接状态已改变回调(onConnectionStateChanged)

{"engineEvent": "onConnectionStateChanged", "state": 0, "reason": 0}

10.本地网络类型发生改变回调(onNetworkTypeChanged)

{"engineEvent": "onNetworkTypeChanged", "type": 0}

11.网络连接中断,且 SDK 无法在 10 秒内连接服务器回调(onConnectionLost)

{"engineEvent": "onConnectionLost"}

12.Token 服务即将过期回调(onTokenPrivilegeWillExpire)

{"engineEvent": "onTokenPrivilegeWillExpire", "token": token}

13.Token 过期回调(onRequestToken)

{"engineEvent": "onRequestToken"}

14.提示频道内谁正在说话、说话者音量及本地用户是否在说话的回调(onAudioVolumeIndication)

{"engineEvent": "onAudioVolumeIndication", "totalVolume": 0, "speakers": speakersArr}

15.监测到活跃用户的回调(onActiveSpeaker)

{"engineEvent": "onActiveSpeaker", "speakerUid": "123"}

16.已发送本地音频首帧的回调(onFirstLocalAudioFrame)

{"engineEvent": "onFirstLocalAudioFrame", "elapsed": 0}

17.已显示本地视频首帧的回调(onFirstLocalVideoFrame)

{"engineEvent": "onFirstLocalVideoFrame", "width": 480, "height": 640, "elapsed": 0}

18.远端音频流状态发生改变回调(onRemoteAudioStateChanged)

{"engineEvent": "onRemoteAudioStateChanged", "uid": "123", "state": 0, "reason": 0, "elapsed": 0}

19.本地音频状态发生改变回调(onLocalAudioStateChanged)

{"engineEvent": "onLocalAudioStateChanged", "state": 0, "error": 0}

20.已显示远端视频首帧回调(onFirstRemoteVideoFrame)

{"engineEvent": "onFirstRemoteVideoFrame", "uid": "123", "width": 480, "height": 640, "elapsed": 0}

21.音频发布状态改变回调(onAudioPublishStateChanged)

{"engineEvent": "onAudioPublishStateChanged", "channel": "909090", "oldState": 0, "newState": 1, "elapseSinceLastState": 0}

22.视频发布状态改变回调(onVideoPublishStateChanged)

{"engineEvent": "onVideoPublishStateChanged", "channel": "909090", "oldState": 0, "newState": 1, "elapseSinceLastState": 0}

23.音频订阅状态发生改变回调(onAudioSubscribeStateChanged)

{"engineEvent": "onAudioSubscribeStateChanged", "channel": "909090", "oldState": 0, "newState": 1, "elapseSinceLastState": 0}

24.视频订阅状态发生改变回调(onVideoSubscribeStateChanged)

{"engineEvent": "onVideoSubscribeStateChanged", "channel": "909090", "oldState": 0, "newState": 1, "elapseSinceLastState": 0}

25.本地或远端视频大小和旋转信息发生改变回调(onVideoSizeChanged)

{"engineEvent": "onVideoSizeChanged", "uid": "123", "width": 480, "height": 640, "rotation": 0}

26.远端视频状态发生改变回调(onRemoteVideoStateChanged)

{"engineEvent": "onRemoteVideoStateChanged", "uid": "123", "state": 0, "reason": 0, "elapsed": 0}

27.地视频状态发生改变回调(onLocalVideoStateChanged)

{"engineEvent": "onLocalVideoStateChanged", "state": 0, "error": 0}

28.通话中远端音频流的统计信息回调(onRemoteAudioStats)

{"engineEvent": "onRemoteAudioStats", "uid": "123", "quality": 0, "networkTransportDelay": 0, "jitterBufferDelay": 0, "audioLossRate": 0, "numChannels": 0, "receivedSampleRate": 0, "receivedBitrate": 0, "totalFrozenTime": 0, "frozenRate": 0}

29.当前通话统计回调。 该回调在通话或直播中每两秒触发一次。(onRtcStats)

{"engineEvent": "onRtcStats", "duration": 0, "txBytes": 0, "rxBytes": 0, "txAudioBytes": 0, "txVideoBytes": 0,
 "rxAudioBytes": 0, "rxVideoBytes": 0, "txKBitrate": 0, "rxKBitrate": 0, "txAudioKBitrate": 0, "rxAudioKBitrate": 0, "txVideoKBitrate": 0, "rxVideoKBitrate": 0, "lastmileDelay": 0, "txPacketLossRate": 0, "rxPacketLossRate": 0, "userCount": 0, "cpuAppUsage": 0, "cpuTotalUsage": 0.0, "gatewayRtt": 0, "memoryAppUsageRatio": 0.0, "memoryTotalUsageRatio": 0.0, "memoryAppUsageInKbytes": 0}

30.通话中每个用户的网络上下行 last mile 质量报告回调(onNetworkQuality)

{"engineEvent": "onNetworkQuality", "uid": "123", "txQuality": 0, "rxQuality": 0}

31.本地视频流统计信息回调(onLocalVideoStats)

{"engineEvent": "onLocalVideoStats", "sentBitrate": 0, "sentFrameRate": 0, "encoderOutputFrameRate": 0, "rendererOutputFrameRate": 0, "sentTargetBitrate": 0, "sentTargetFrameRate": 0, "qualityAdaptIndication": 0, "encodedBitrate": 0, "encodedFrameWidth": 640, "encodedFrameHeight": 480, "encodedFrameCount": 0, "codecType": 0}

32.通话中本地音频流的统计信息回调(onLocalAudioStats)

{"engineEvent": "onLocalAudioStats", "numChannels": 0, "sentSampleRate": 0, "sentBitrate": 0}

33.通话中远端视频流的统计信息回调(onRemoteVideoStats)

{"engineEvent": "onRemoteVideoStats", "uid": "123", "delay": 0, "width": 480, "height": 640, "receivedBitrate": 0, "decoderOutputFrameRate": 0, "rendererOutputFrameRate": 0, "packetLossRate": 0, "rxStreamType": 0, "totalFrozenTime": 0, "frozenRate": 0}

34.本地音乐文件播放已结束回调(onAudioMixingFinished)

{"engineEvent": "onAudioMixingFinished"}

35.本地音效文件播放已结束回调(onAudioEffectFinished)

{"engineEvent": "onAudioEffectFinished", "soundId": 6060}

36.RTMP 推流状态发生改变回调(onRtmpStreamingStateChanged)

{"engineEvent": "onRtmpStreamingStateChanged", "url": "", "state": 0, "errorCode": 0}

37.RTMP 推流事件回调(onRtmpStreamingEvent)已废弃

{"engineEvent": "onRtmpStreamingEvent", "url": "", "eventCode": 0}

38.开启旁路推流的结果回调(onStreamPublished)已废弃

{"engineEvent": "onStreamPublished", "url": "", "errorCode": 0}

39.停止旁路推流的结果回调(onStreamUnpublished)已废弃

{"engineEvent": "onStreamUnpublished", "url": ""}

40.旁路推流设置被更新回调(onTranscodingUpdated)

{"engineEvent": "onTranscodingUpdated"}

41.输入外部视频流状态回调(onStreamInjectedStatus)

{"engineEvent": "onStreamInjectedStatus", "url": "", "uid": "123", "status": 0}

42.音视频流回退事件回调(onRemoteSubscribeFallbackToAudioOnly)

{"engineEvent": "onRemoteSubscribeFallbackToAudioOnly", "isFallbackOrRecover": true, "uid": "123"}

43.媒体设备事件回调(onAudioRouteChanged)

{"engineEvent": "onAudioRouteChanged", "routing": 0}

44.报告本地人脸检测结果(onFacePositionChanged)

{"engineEvent": "onFacePositionChanged", "width": 640, "height": 480, "faces": facesArr}

45.跨频道媒体流转发状态发生改变回调(onChannelMediaRelayStateChanged)

{"engineEvent": "onChannelMediaRelayStateChanged", "state": 0, "error": 0}

46.跨频道媒体流转发事件回调(onChannelMediaRelayEvent)

{"engineEvent": "onChannelMediaRelayEvent", "event": 0}

47.已完成远端视频首帧解码回调(onFirstRemoteVideoDecoded)

{"engineEvent": "onFirstRemoteVideoDecoded", "uid": "123", "width": 640.0, "height": 480.0, "elapsed": 0}

48.已接收远端音频首帧的回调(onFirstRemoteAudioFrame)

{"engineEvent": "onFirstRemoteAudioFrame", "uid": "123", "elapsed": 0}

49.已解码远端音频首帧的回调(onFirstRemoteAudioDecoded)

{"engineEvent": "onFirstRemoteAudioDecoded", "uid": "123", "elapsed": 0}

50.远端用户暂停/重新发送视频回调(onUserMuteVideo)

{"engineEvent": "onUserMuteVideo", "uid": "123", "muted": true}

51.远端用户音频静音回调(onUserMuteAudio)

{"engineEvent": "onUserMuteAudio", "uid": "123", "muted": true}

52.其他用户启用/关闭视频回调(onUserEnableVideo)

{"engineEvent": "onUserEnableVideo", "uid": "123", "enabled": true}

53.其他用户启用/关闭本地视频回调(onUserEnableLocalVideo)

{"engineEvent": "onUserEnableLocalVideo", "uid": "123", "enabled": true}

54.麦克风状态已改变回调(onMicrophoneEnabled)

{"engineEvent": "onMicrophoneEnabled", "enabled": true}

55.网络连接中断回调(onConnectionInterrupted)

{"engineEvent": "onConnectionInterrupted"}

56.连接已被禁止回调(onConnectionBanned)

{"engineEvent": "onConnectionBanned"}

57.通话中远端音频流传输的统计信息回调(onRemoteAudioTransportStats)

{"engineEvent": "onRemoteAudioTransportStats", "uid": "123", "delay": 0, "lost": 0, "rxKBitRate": 0}

58.通话中远端视频流传输的统计信息回调(onRemoteVideoTransportStats)

{"engineEvent": "onRemoteVideoTransportStats", "uid": "123", "delay": 0, "lost": 0, "rxKBitRate": 0}

59.远端音频质量回调(onAudioQuality)

{"engineEvent": "onAudioQuality", "uid": "123", "quality": 0, "delay": 0, "lost": 0}

60.摄像头就绪回调(onCameraReady)

{"engineEvent": "onCameraReady"}

61.发生错误回调(onVideoStopped)

{"engineEvent": "onVideoStopped"}

隐私、权限声明

1. 本插件需要申请的系统权限列表:

NSMicrophoneUsageDescription NSCameraUsageDescription

2. 本插件采集的数据、发送的服务器地址、以及数据用途说明:

anyRTC采集音视频信息,有关文档见https://docs.anyrtc.io

3. 本插件是否包含广告,如包含需详细说明广告表达方式、展示频率:

许可协议

请参考开源项目地址的开源协议
