更新记录

1.0.4(2021-10-14)

1、组件属性调整 2、补充说明文档

1.0.3(2021-10-14)

1、样式优化,editor滚动区域优化计算 2、示例项目优化

1.0.2(2021-10-12)

1、示例项目更新

查看更多

平台兼容性

Vue2 Vue3
App 快应用 微信小程序 支付宝小程序 百度小程序 字节小程序 QQ小程序
× × × × × ×
钉钉小程序 快手小程序 飞书小程序 京东小程序
× × × ×
H5-Safari Android Browser 微信浏览器(Android) QQ浏览器(Android) Chrome IE Edge Firefox PC-Safari
× × × × × × × × ×

自定义富文本编辑器

前言

照着腾讯文档小程序开发了微信小程序富文本编辑器组件,这几天做个整理,如有这个需求可以前往腾讯文档小程序操作看看实际效果。毕竟参照的是微信自家小程序,无法做到百分百效果,只能按现有开放api尽可能实现。
项目地址:
https://github.com/chellel/wechat-editor-project
editor富文本编辑器组件官方文档: https://developers.weixin.qq.com/miniprogram/dev/component/editor.html

使用方法

<template>
    <cu-editor ref="editor" :url="uploadUrl" :header="header" :formData="formData" :content="content" @before="onUploadBefore" @update="onUpdate" @save="onSave"></cu-editor>
<template>
<script>
import cuEditor from '@/components/cu-editor/cu-editor'
export default {
    components: {
      cuEditor
    }
}
</script>

传入参数详解

属性名 类型 默认值 必填 说明
placeholder String 请输入内容 editor属性,提示信息
showImgSize Boolean false editor属性,点击图片时显示图片大小控件
showImgToolbar Boolean false editor属性,点击图片时显示工具栏控件
showImgResize Boolean false editor属性,点击图片时显示修改尺寸控件
content String 必填 编辑器内容
maxSize Number 5 chooseImage参数,最大文件大小,上传文件前校验是否符合规则,单位MB
count Number 5 chooseImage参数,最多可以选择的图片张数
sizeType Array ['original', 'compressed'] cchooseImage参数,所选的图片的尺寸
sourceType Array ['album', 'camera'] chooseImage参数,选择图片的来源
noAllowType header [] 不允许上传的图片类型
url String 必填 uploadFile参数,必填
header Object {} uploadFile参数
formData Object {} uploadFile参数
name String file uploadFile参数

关于editor开发注意事项

1、包装成组件时,bindready编辑器初始化完成时触发,通过选择器选择时,需要将选择器的选择范围更改为当前component中。
wx.createSelectorQuery().select('#editor').context(function (res) {
that.editorCtx = res.context
}).exec()
wx.createSelectorQuery().in(this).select('#editor').context(function (res) {
that.editorCtx = res.context
}).exec()
2、页面调用组件时,组件不能与editor同名,即定义一个新的组件名,正确引用:
import cuEditor from '@/components/cu-editor/cu-editor'

<cu-editor></cu-editor>

否则会受到小程序css影响。小程序本身editor标签有css样式: editor { display: block; position: relative; box-sizing: border-box; -webkit-user-select: text; user-select: text; outline: 0; overflow: hidden; width: 100%; height: 200px; min-height: 200px; }

3、监听键盘调起时,注释wx.pageScrollTo 直接执行

that.updatePosition(keyboardHeight) that.editorCtx.scrollIntoView()

            uni.onKeyboardHeightChange(res => {
                let keyboardHeight = this.keyboardHeight
                if (res.height === keyboardHeight) return

                this.keyboardHeight = res.height;
                const duration = res.height > 0 ? res.duration * 1000 : 0
                keyboardHeight = res.height;
                setTimeout(() => {
                    uni.pageScrollTo({
                        scrollTop: 0,
                        success: () => {
                            this.updatePosition(keyboardHeight)
                            this.editorCtx.scrollIntoView() //使得编辑器光标处滚动到窗口可视区域内
                        }
                    })
                }, duration)
            })
4、setContents设置编辑器内容时,会自动聚集到编辑器中,并滚动到窗口可视区域内,需执行完后调用pageScrollTo滚动回顶部,哦避免闪屏,使用setTimeout延迟执行
            setValue(value) {
                if (this.editorCtx) {
                    this.editorCtx.setContents({
                        html: value,
                        success: () => {
                            this.getContents(res => {
                                this.onEditorInput({
                                    detail: {
                                        html: res.html,
                                        text: res.text
                                    }
                                })
                                this.$emit('update', res)
                            })
                        }
                    })
                }
            }
其他富文本相关方法,详见官方文档:https://developers.weixin.qq.com/miniprogram/dev/api/media/editor/EditorContext.format.html
修改样式 EditorContext.format
this.editorCtx.format('fontSize', '14px');
插入文本 EditorContext.insertText

在插入目标文字时,将值设为\n',可以实现换行 this.editorCtx.insertText({ text: '\n' });

插入图片 EditorContext.insertImage

               that.editorCtx.insertImage({
                        src: that.uploadHost + json.data.path,
                        data: {
                            id: file.uid
                        },
                        // extClass:'editor-img',
                        extClass:'editor--editor-img', //添加到图片 img标签上的类名为editor-img,设置前缀editor--才生效。部分机型点击图片右边的光标时不灵敏,需在editor-img将图片宽度调小 max-width:98%;
                        // width: '100%',
                        success() {
                            //真机会自动插入一行空格
                            //   that.editorCtx.insertText({ text: '\n' });  //自动插入一个空行,方便用户移动光标
                        }
                    })

...

    .editor-img{
        max-width: 98%!important;
    }

//保存时需处理掉editor--的class前缀

/**
  * 处理html中的图片地址和宽度
  * resetClass:  是否将class="editor-- 更改为class="
  * EditorContext.setContents时img标签的class会自带一个前缀editor--,如原class="editor-img",EditorContext.setContents后class="editor--editor-img" */
export const handleHtmlImage = (html = '', resetClass) => {
    var newHtml = html.replace(/<img [^>]*src=['"]([^'"]+)[^>]*>/ig, function(match, src) {
        let result = match
        //返回每个匹配的字符串
        if(resetClass) result = result.replace(/class=\"(.*)editor--/gi,'class="');
        result = result.replace(/\<img/"max-width:100%;height:auto"');
        return result;
    });
    return newHtml;
}

设置 editor placeholder 样式

  .ql-editor.ql-blank:before {
       color: #B2B2B2;
       font-style: normal;
    }

目前仍存在的问题

bug1、editor调用uni.hideKeyboard()隐藏软键盘的api,不能关闭软键盘,,隐藏键盘只能用EditorContext.blur,这样会导致一个问题,见bug2。同时也不支持拉起键盘操作。

参考:请问editor组件控制拉起键盘操作支持吗? https://developers.weixin.qq.com/community/develop/doc/0006eeb6ae8cf0e7f3293e13f56400?highLine=editor%25E6%2598%25BE%25E7%25A4%25BA%25E9%2594%25AE%25E7%259B%2598

小程序技术专员-sanford 2019-09-20

不支持的。iOS无法通过接口拉起键盘,必须用户点击;安卓则可以。所以,终究是不一致,不行。。

bug2、由于隐藏键盘只能用EditorContext.blur,即调用了失焦api。在设置格式面板时,会失去当前焦点光标以及高亮显示状态。

总结

该组件主要为微信editor组件的api调用集成封装,因此受到的限制同文档描述一致,即编辑器内支持部分 HTML 标签和内联样式,不支持class和id,支持的标签详见:https://developers.weixin.qq.com/miniprogram/dev/component/editor.html。 不满足的标签会被忽略,\<div>会被转行为\<p>储存。 这也是为什么在做富文本解析时,仅仅用rich-text组件无法有效还原html内容,在解析内容的时候就需要将内容中的HTML标签转换成微信小程序所支持的标签。因此最好方式是引入市场封装好的富文本解析插件去解析html。 所以,开发者需要自行权衡在做富文本编辑开发时,是否使用微信自带的editor组件,或者参考腾讯文档小程序采用webview内嵌网页等方式去渲染。

开发富文本编辑器可参考其他文档:

小程序富文本编辑器editor初体验:(https://www.jianshu.com/p/a932639ba7a6) 如果是微信原生开发,将demo组件中的相关dom元素标签和api换成微信原生即可。

如有其他技术需要支持或者你有好的bug修复方案,可联系qq:1010603372。

隐私、权限声明

1. 本插件需要申请的系统权限列表:

2. 本插件采集的数据、发送的服务器地址、以及数据用途说明:

插件不采集任何数据

3. 本插件是否包含广告,如包含需详细说明广告表达方式、展示频率:

许可协议

MIT协议

使用中有什么不明白的地方,就向插件作者提问吧~ 我要提问
