更新记录

1.1.0（2023-09-11）

  1. 解决iOS运行异常问题。

1.0.9（2023-08-16）

1、修复iOS打包缺少依赖库导致失败问题。

1.0.8（2023-08-14）

1、修复iOS打包失败问题。

查看更多

平台兼容性

Android Android CPU类型 iOS
适用版本区间：5.0 - 12.0 armeabi-v7a：支持，arm64-v8a：支持，x86：支持 适用版本区间：9 - 14

原生插件通用使用流程：

  1. 购买插件，选择该插件绑定的项目。
  2. 在HBuilderX里找到项目，在manifest的app原生插件配置中勾选模块，如需要填写参数则参考插件作者的文档添加。
  3. 根据插件作者的提供的文档开发代码，在代码中引用插件，调用插件功能。
  4. 打包自定义基座，选择插件，得到自定义基座，然后运行时选择自定义基座，进行log输出测试。
  5. 开发完毕后正式云打包

付费原生插件目前不支持离线打包。
Android 离线打包原生插件另见文档 https://nativesupport.dcloud.net.cn/NativePlugin/offline_package/android
iOS 离线打包原生插件另见文档 https://nativesupport.dcloud.net.cn/NativePlugin/offline_package/ios

注意事项：使用HBuilderX2.7.14以下版本，如果同一插件且同一appid下购买并绑定了多个包名，提交云打包界面提示包名绑定不一致时，需要在HBuilderX项目中manifest.json->“App原生插件配置”->”云端插件“列表中删除该插件重新选择

概述

  • 支持导出Excel表
  • 支持读取Excel表：支持xls、xlsx格式
  • 支持自定义路径导出或读取Excel表
  • 支持导出Excel表可插入图片
  • 支持读取Excel表可多sheet读取

温馨提示 如何调用插件

    var getModel = uni.requireNativePlugin("yuange-TwinsYGExcelModule");

导出Excel表单Sheet

    const _this = this;
    getModel.callNativeExportExcel({
                        'outFilePath': '自定义输出的路径地址,例如:/sdcard/aaa.xls',
                        'inExcelData': 'excel数据:注意要按照规范格式传参,json格式，详见:导出excel传参规范',
        },
        (ret) => {
        //返回输出的结果，包含输出的文件所在路径
        _this.title = JSON.stringify(ret);
    })

导出Excel表多Sheet

    const _this = this;
    getModel.callNativeExportExcelMoreSheet({
                        'outFilePath': '自定义输出的路径地址,例如:/sdcard/aaa.xls',
                        'inExcelData': 'excel数据:注意要按照规范格式传参,json格式，详见:导出excel传参规范',
        },
        (ret) => {
        //返回输出的结果，包含输出的文件所在路径
        _this.title = JSON.stringify(ret);
    })

导出Excel传参规范

单sheet格式：
"excelData": [
              {
                  "sheetName":"名单", //sheetName
                  "cell_title": "姓名", //标题
                  "cell_title_font_size": "12",//标题字体大小
                  "cell_title_color": "9", //标题字体颜色
                  "cell_title_bg_color": "12", //标题背景色
                  "cell_title_align": "2", //标题位置
                  "cell_title_border_color": "0",//标题单元格边框颜色
                  "cell_value_font_size": "10",//单元格列的值字体大小
                  "cell_value_color": "32767",//单元格列的值字体颜色
                  "cell_value_bg_color": "9",//单元格列的值背景色
                  "cell_value_align": "2", //单元格列的值位置
                  "cell_value_border_color": "0",//单元格列的值的边框颜色
                  "cell_title_rowHight": "350", //单元格标题的高度
                  "cell_value_rowHight": "350", //单元格列的值高度
                  "cell_columWidth": "15", //设置列宽度
                  "cell_value": [ //列的值数组
                      "王二",
                      "张三",
                      "李四",
                      "老七"
                  ],
                  "picture_path":"/sdcard/pic.png", //插入图片
                  "picture_cellRow":"5", //图片所在行
                  "picture_cellCol":"5" //图片所在列
              }
            ]
多sheet格式：
"data": [{
                "excelData": [{
                    "sheetName": "名单",
                    "cell_title": "姓名",
                    "cell_title_font_size": "12",
                    "cell_title_color": "9",
                    "cell_title_bg_color": "12",
                    "cell_title_align": "2",
                    "cell_title_border_color": "0",
                    "cell_value_font_size": "10",
                    "cell_value_color": "32767",
                    "cell_value_bg_color": "9",
                    "cell_value_align": "2",
                    "cell_value_border_color": "0",
                    "cell_title_rowHight": "350",
                    "cell_value_rowHight": "350",
                    "cell_columWidth": "15",
                    "cell_value": [
                        "王二",
                        "张三",
                        "李四",
                        "老七"
                    ],
                    "picture_path": "/sdcard/pic.png",
                    "picture_cellRow": "5",
                    "picture_cellCol": "5"
                }]
            },
            {
                "excelData": [{
                    "sheetName": "成绩",
                    "cell_title": "分数",
                    "cell_title_font_size": "12",
                    "cell_title_color": "9",
                    "cell_title_bg_color": "12",
                    "cell_title_align": "2",
                    "cell_title_border_color": "0",
                    "cell_value_font_size": "10",
                    "cell_value_color": "32767",
                    "cell_value_bg_color": "9",
                    "cell_value_align": "2",
                    "cell_value_border_color": "0",
                    "cell_title_rowHight": "350",
                    "cell_value_rowHight": "350",
                    "cell_columWidth": "15",
                    "cell_value": [
                        "90",
                        "85",
                        "100",
                        "89"
                    ]
                }]
            }
        ]

字体、背景、边框颜色值数字参考表定义：

    public static final Colour BLACK = new Colour(32767, "black", 0, 0, 0);
    public static final Colour WHITE = new Colour(9, "white", 255, 255, 255);
    public static final Colour DEFAULT_BACKGROUND1 = new Colour(0, "default background", 255, 255, 255);
    public static final Colour DEFAULT_BACKGROUND = new Colour(192, "default background", 255, 255, 255);
    public static final Colour PALETTE_BLACK = new Colour(8, "black", 1, 0, 0);
    public static final Colour RED = new Colour(10, "red", 255, 0, 0);
    public static final Colour BRIGHT_GREEN = new Colour(11, "bright green", 0, 255, 0);
    public static final Colour BLUE = new Colour(12, "blue", 0, 0, 255);
    public static final Colour YELLOW = new Colour(13, "yellow", 255, 255, 0);
    public static final Colour PINK = new Colour(14, "pink", 255, 0, 255);
    public static final Colour TURQUOISE = new Colour(15, "turquoise", 0, 255, 255);
    public static final Colour DARK_RED = new Colour(16, "dark red", 128, 0, 0);
    public static final Colour GREEN = new Colour(17, "green", 0, 128, 0);
    public static final Colour DARK_BLUE = new Colour(18, "dark blue", 0, 0, 128);
    public static final Colour DARK_YELLOW = new Colour(19, "dark yellow", 128, 128, 0);
    public static final Colour VIOLET = new Colour(20, "violet", 128, 128, 0);
    public static final Colour TEAL = new Colour(21, "teal", 0, 128, 128);
    public static final Colour GREY_25_PERCENT = new Colour(22, "grey 25%", 192, 192, 192);
    public static final Colour GREY_50_PERCENT = new Colour(23, "grey 50%", 128, 128, 128);
    public static final Colour PERIWINKLE = new Colour(24, "periwinkle%", 153, 153, 255);
    public static final Colour PLUM2 = new Colour(25, "plum", 153, 51, 102);
    public static final Colour IVORY = new Colour(26, "ivory", 255, 255, 204);
    public static final Colour LIGHT_TURQUOISE2 = new Colour(27, "light turquoise", 204, 255, 255);
    public static final Colour DARK_PURPLE = new Colour(28, "dark purple", 102, 0, 102);
    public static final Colour CORAL = new Colour(29, "coral", 255, 128, 128);
    public static final Colour OCEAN_BLUE = new Colour(30, "ocean blue", 0, 102, 204);
    public static final Colour ICE_BLUE = new Colour(31, "ice blue", 204, 204, 255);
    public static final Colour DARK_BLUE2 = new Colour(32, "dark blue", 0, 0, 128);
    public static final Colour PINK2 = new Colour(33, "pink", 255, 0, 255);
    public static final Colour YELLOW2 = new Colour(34, "yellow", 255, 255, 0);
    public static final Colour TURQOISE2 = new Colour(35, "turqoise", 0, 255, 255);
    public static final Colour VIOLET2 = new Colour(36, "violet", 128, 0, 128);
    public static final Colour DARK_RED2 = new Colour(37, "dark red", 128, 0, 0);
    public static final Colour TEAL2 = new Colour(38, "teal", 0, 128, 128);
    public static final Colour BLUE2 = new Colour(39, "blue", 0, 0, 255);
    public static final Colour SKY_BLUE = new Colour(40, "sky blue", 0, 204, 255);
    public static final Colour LIGHT_TURQUOISE = new Colour(41, "light turquoise", 204, 255, 255);
    public static final Colour LIGHT_GREEN = new Colour(42, "light green", 204, 255, 204);
    public static final Colour VERY_LIGHT_YELLOW = new Colour(43, "very light yellow", 255, 255, 153);
    public static final Colour PALE_BLUE = new Colour(44, "pale blue", 153, 204, 255);
    public static final Colour ROSE = new Colour(45, "rose", 255, 153, 204);
    public static final Colour LAVENDER = new Colour(46, "lavender", 204, 153, 255);
    public static final Colour TAN = new Colour(47, "tan", 255, 204, 153);
    public static final Colour LIGHT_BLUE = new Colour(48, "light blue", 51, 102, 255);
    public static final Colour AQUA = new Colour(49, "aqua", 51, 204, 204);
    public static final Colour LIME = new Colour(50, "lime", 153, 204, 0);
    public static final Colour GOLD = new Colour(51, "gold", 255, 204, 0);
    public static final Colour LIGHT_ORANGE = new Colour(52, "light orange", 255, 153, 0);
    public static final Colour ORANGE = new Colour(53, "orange", 255, 102, 0);
    public static final Colour BLUE_GREY = new Colour(54, "blue grey", 102, 102, 204);
    public static final Colour GREY_40_PERCENT = new Colour(55, "grey 40%", 150, 150, 150);
    public static final Colour DARK_TEAL = new Colour(56, "dark teal", 0, 51, 102);
    public static final Colour SEA_GREEN = new Colour(57, "sea green", 51, 153, 102);
    public static final Colour DARK_GREEN = new Colour(58, "dark green", 0, 51, 0);
    public static final Colour OLIVE_GREEN = new Colour(59, "olive green", 51, 51, 0);
    public static final Colour BROWN = new Colour(60, "brown", 153, 51, 0);
    public static final Colour PLUM = new Colour(61, "plum", 153, 51, 102);
    public static final Colour INDIGO = new Colour(62, "indigo", 51, 51, 153);
    public static final Colour GREY_80_PERCENT = new Colour(63, "grey 80%", 51, 51, 51);
    public static final Colour AUTOMATIC = new Colour(64, "automatic", 255, 255, 255);

单元格位置数字参考表定义：

    public static Alignment GENERAL = new Alignment(0, "general");
    public static Alignment LEFT = new Alignment(1, "left");
    public static Alignment CENTRE = new Alignment(2, "centre");
    public static Alignment RIGHT = new Alignment(3, "right");
    public static Alignment FILL = new Alignment(4, "fill");
    public static Alignment JUSTIFY = new Alignment(5, "justify");

读取Excel表：xls格式

   const _this = this;
   var ret = getModel.callNativeReadExcel({
           'inFilePath': '自定义文件路径地址,例如:/sdcard/aaa.xls',
           'columTitles':'姓名,年级,年龄'
        },
    (ret) => {
        //返回输出的结果，包含输出的文件所在路径
        _this.title = JSON.stringify(ret);
    })

读取Excel表：xlsx格式

   const _this = this;
   var ret = getModel.callNativeReadExcelXlsx({
           'inFilePath': '自定义文件路径地址,例如:/sdcard/bbb.xlsx',
           'columTitles':'姓名,年级,年龄'
        },
    (ret) => {
        //返回输出的结果，包含输出的文件所在路径
        _this.title = JSON.stringify(ret);
    })

读取Excel表多sheet

   const _this = this;
   var ret = getModel.callNativeReadExcelMoreSheets({
           'inFilePath': '自定义文件路径地址,例如:/sdcard/ccc.xlsx',
        },
    (ret) => {
        //返回输出的结果，包含输出的文件所在路径
        _this.title = JSON.stringify(ret);
    })

注意事项

1、iOS和安卓用法接口一致，Android支持以上所有功能。iOS目前只支持导出excel表格包括单sheet、多sheet，但不支持读取，后面会增加读取功能。 2、iOS支持对应的接口：callNativeExportExcel、callNativeExportExcelMoreSheet。 3、iOS不需要传入自定义输出路径，默认会自动生成路径回调给前台。

例如iOS导出多sheet表格用法：

    const _this = this;
    getModel.callNativeExportExcelMoreSheet({
                        'inExcelData': 'excel数据:注意要按照规范格式传参,json格式，详见:导出excel传参规范',
        },
        (ret) => {
        //返回输出的结果，包含输出的文件所在路径
        _this.title = JSON.stringify(ret);
    })
如有问题咨询可以联系QQ 2729404527

隐私、权限声明

1. 本插件需要申请的系统权限列表：

存储权限 WRITE_EXTERNAL_STORAGE READ_EXTERNAL_STORAGE

2. 本插件采集的数据、发送的服务器地址、以及数据用途说明：

插件不采集任何数据

3. 本插件是否包含广告，如包含需详细说明广告表达方式、展示频率：

无
