更新记录
1.0.0(2023-06-02)
组件首次发布
平台兼容性
Vue2 | Vue3 |
---|---|
√ | × |
App | 快应用 | 微信小程序 | 支付宝小程序 | 百度小程序 | 字节小程序 | QQ小程序 |
---|---|---|---|---|---|---|
app-vue app-nvue | × | √ | × | × | × | × |
钉钉小程序 | 快手小程序 | 飞书小程序 | 京东小程序 |
---|---|---|---|
× | × | × | × |
H5-Safari | Android Browser | 微信浏览器(Android) | QQ浏览器(Android) | Chrome | IE | Edge | Firefox | PC-Safari |
---|---|---|---|---|---|---|---|---|
√ | √ | √ | √ | √ | √ | √ | √ | √ |
ECharts封装全端通用组件(支持APP/H5/微信小程序等)
- 支持支持APP/H5/微信小程序等平台使用
- 函数及属性说明
序号 | 函数名称 | 函数说明 |
---|---|---|
1 | onEchartsComplete() | 组件函数,echarts初始化完成 |
2 | echartClick(e) | 组件函数,echarts点击事件函数 |
3 | option | 组件属性,与echarts的options参数格式一致 |
-
初始化完成函数 onEchartsComplete()说明:
该函数为echarts初始化完成的回调函数,可在该函数中改变echarts的option
-
echarts点击事件函数 echartClick(e)说明:
该函数返回echarts点击事件一致的参数,示例如下: { "componentType":"series", "componentSubType":"line", "componentIndex":0, "seriesType":"line", "seriesIndex":0, "seriesId":"\u0000series\u00000\u00000", "seriesName":"series\u00000", "name":"-8:00", "dataIndex":7, "data":323, "value":323, "color":"#EE82EE", "dimensionNames":[ "x", "y" ], "encode":{ "x":[ 0 ], "y":[ 1 ] }, "$vars":[ "seriesName", "name", "value" ], "type":"click" }
注意事项、注意事项、注意事项
1、导入插件后请将插件中的echarts.js文件复制一份到你的项目static目录下; 2、也可以自行从echarts官网(https://echarts.apache.org/zh/builder.html)构建你的echarts.js文件替换插件的echarts.js文件 3、点击HBuilderX预览,点击事件失效问题,在项目main.js中最底下添加如下代码: // #ifdef H5 window.wx = {} // #endif
-
使用示例
<template> <view class="uni-column"> <view class="charts-box"> <jushiEcharts :option="option" @onEchartsComplete="onEchartsComplete" @echartClick="echartClick"></jushiEcharts> </view> </view> </template> <script> import jushiEcharts from '@/uni_modules/jushi-uniECharts/components/jushi-echarts.vue' export default { components: { jushiEcharts }, data() { return { option: {} } }, onLoad() { }, created() { this.$nextTick(() => { setTimeout(()=>{ // this.getData() },1000) }) }, methods: { onEchartsComplete(){//echarts初始化完成回调 this.getData() }, echartClick(e){//echarts点击事件 console.log(e.dataIndex) }, getData() { var date = new Date() var hour = date.getHours() let xArr = [] let dArr = [] for (var i = 1; i <= 24; i++) { xArr.push((hour - i) + ':00') dArr.push(i * (Math.floor(Math.random() * 20 + 1))) } let xData = ['12:00', '13:00', '14:00'] let datas = [99, 66, 88] this.option = this.getOption(xArr.reverse(), dArr.reverse()) }, getChartData(xData, datas) { return { "categories": xData, "series": [{ "name": "", "data": datas }] } }, getOption(xData, datas) { return { title: { text: '24小时数据趋势图', textStyle: { color: '#EE82EE', fontSize: 16 }, left: '45%', top: '5', bottom: '10' }, "tooltip": { "show": true, "trigger": "axis", "axisPointer": { "lineStyle": { "color": "transparent" } } }, "grid": { "left": "5%", "top": "15%", "right": "5%", "bottom": "85" }, "dataZoom": [{ "type": "inside", "start": 0, "end": 50, "zoomLock": true }, { "type": "slider", "start": 0, "end": 50, "zoomLock": true, "bottom": "10", "height": 18, "brushSelect": false, "showDetail": false } ], "xAxis": [{ "type": "category", "data": xData, axisTick: { show: false }, axisLine: { show: false, lineStyle: { color: '#6A989E', } }, axisLabel: { inside: false, textStyle: { color: '#1a1a1a', // x轴颜色 fontWeight: 'normal', fontSize: 12, lineHeight: 22 }, interval: 0, rotate: 55, // align: 'right', margin: 10 }, "boundaryGap": true }], "yAxis": [{ "name": "个", "nameGap": 8, "offset": -10, nameTextStyle: { color: '#999999', fontSize: 12 }, splitLine: { lineStyle: { type: 'dashed', color: 'rgba(135,140,147,0.2)' }, }, axisLine: { show: true, lineStyle: { type: 'dashed', color: 'rgba(135,140,147,0.2)' } }, axisTick: { show: false }, axisLabel: { formatter: '{value}', color: '#999999', fontSize: 11 } }], "series": [{ "symbolSize": 6, "symbol": "emptyCircle", "type": "line", smooth: false, //平滑曲线 "yAxisIndex": 0, "data": datas, "itemStyle": { "normal": { "borderWidth": 1, "color": "#EE82EE" } }, "label": { "show": true, "position": "top", "distance": 2, "fontSize": 12, "color": "#EE82EE" }, }] } } } } </script> <style> .charts-box { width: 100%; height: 600rpx; } </style>
-
备注
欢迎来邮件咨询和讨论,邮箱:1052775690@qq.com
